Carrier SmartVu control User Manual

SRDC-UG-2-14-000
REVISION
DATE
PAGE
19 Series Carrier®
SmartVu
TM
–
Controls IOM
2.3
Dec 4, 2020
140 OF 168
140
29
hdpv_tgt
-
0
%
Head Pres Valve Tgt Pos
30
HDPV_OUT
-
0
mA
Head Pres Output mA
31
HDPV_OU2
-
0
mA
Head Pres2 Output mA
32
TFR_HIGH
OFF_ON
OFF
-
Tower Fan Relay High
33
TFR_LOW
OFF_ON
OFF
-
Tower Fan Relay Low
34
DIFF_OUT
-
0
mA
Diffuser Output mA
35
LLC_EXVO
-
0
mA
Liquid Level EXV Output
36
llc_exvt
-
0
%
Liquid Level EXV Target
37
OP_VFD
-
0
mA
Oil Pump VFD Output mA
38
op_vfd_t
-
0
%
Oil Pump VFD Target
39
POW_REQ
OFF_ON
OFF
-
Marine Pwr Req Output
40
FC_MODE
NO_YES
NO
-
Free Cooling Mode
*Depends on the selected language (English by default).
DV_OUT - 19DV Outputs Status
Name
Range
Default
Unit
Displayed text*
1
REF_PUMP
OFF_ON
OFF
-
Refrigerant Pump
2
GV2_OUT
-
0
mA
Guide Vane2 Output
3
ECBY_VLV
OFF_ON
OFF
-
ECO Liquid Bypass Valve
4
ECON_IV
OFF_ON
OFF
-
ECO Isolation VLV
5
COND_CV
OFF_ON
OFF
-
Cond Valve (Ref Lube)
6
EVAP_CV
OFF_ON
OFF
-
Evap Valve (Ref Lube)
7
EVAP_DCV
OFF_ON
OFF
-
Evaporator Drain Valve
8
COND_DCV
OFF_ON
OFF
-
Condenser Drain Valve
9
COND_PSV
OFF_ON
OFF
-
Purge Cond Valve
