Carrier SmartVu control User Manual

SRDC-UG-2-14-000
REVISION
DATE
PAGE
19 Series Carrier®
SmartVu
TM
–
Controls IOM
2.3
Dec 4, 2020
142 OF 168
142
7
cdw_off
-68.95 to 68.95
-10 to 10
0.00
0
kPa
PSI
Condenser Delta P Offset
8
cdw_pull
-
0.00
0
^C
^F
Cond Water Pulldown/Min
9
CHWP
OFF_ON
OFF
-
Chilled Water Pump
10
CHW_FLOW
NO_YES
NO
-
Chilled Water Flow
11
CHW_FV
-
0.00
0
l/min
GPM
Chilled Water Flow Value
12
EVAP_EWP
-
0.00
0
kPa
PSIG
Entering Chilled Water P
13
EVAP_LWP
-
0.00
0
kPa
PSIG
Leaving Chilled Water P
14
chw_pd
-
0.00
0
kPa
PSI
Chilled Water Delta P
15
chw_off
-68.95 to 68.95
-10 to 10
0.00
0
kPa
PSI
Chilled Delta P Offset
16
chw_pull
-
0.00
0
^C
^F
Chill Water Pulldown/Min
17
CHWF_IN
-
0
mA
Chilled Water Flow Input
18
CDWF_IN
-
0
mA
Cond Water Flow Input
19
CHW_PDMA
-
0
mA
Chilled Water Pres Drop
20
CDW_PDMA
-
0
mA
Cond Water Pres Drop
21
EVAP_FS
OPEN_CLOSE
OPEN
-
Evap Water Flow Switch
22
COND_FS
OPEN_CLOSE
OPEN
-
Cond Water Flow Switch
23
TFR_HI
OFF_ON
OFF
-
Tower Fan Relay High
24
TFR_LO
OFF_ON
OFF
-
Tower Fan Relay Low
