Carrier SmartVu control User Manual

SRDC-UG-2-14-000
REVISION
DATE
PAGE
19 Series Carrier®
SmartVu
TM
–
Controls IOM
2.3
Dec 4, 2020
147 OF 168
147
Name
Range
Default
Unit
Displayed text*
1
chil_typ
0 to 3
0
-
Chiller Type
2
blank
-
-
-
19XR6/7=0
3
blank
-
-
-
19XR2~5/C/D/E/V=1
4
blank
-
-
-
19DV=2
5
blank
-
-
-
19XRF=3
6
vfd_opt
0 to 9
0
-
VFD/Starter Option
7
blank
-
-
-
Starter with ISM = 0
8
blank
-
-
-
FS VFD with ISM = 1
9
blank
-
-
-
Carrier 32VS VFD = 2
10
blank
-
-
-
Rockwell LF2 VFD = 3
11
blank
-
-
-
Eaton VFD = 4
12
blank
-
-
-
Rockwell STD VFD = 5
13
blank
-
-
-
Danfoss VFD = 7
14
blank
-
-
-
Benshaw Starter = 8
15
blank
-
-
-
STEP HV VFD = 9
16
unit_typ
0 to 1
0
-
Unit Type
17
blank
-
-
-
Cool Only=0, Heat Mach=1
18
ref_typ
0 to 2
0
-
Refrigerant Type
19
blank
-
-
-
R134a=0,R513A=1,R515A=2
20
comp_typ
0 to 1
1
-
Comp(1Stage=0, 2Stage=1)
21
chmedium
WATER_BRINE
WATER
-
Chilled Medium Type
22
cond_typ
0 to 1
0
-
Cond Refrig Shell MAWP
23
blank
-
-
-
185PSI=0, 300PSI=1
24
comp_pre
0 to 1
0
-
Comp Refrig Press
25
blank
-
-
-
44PSI=0, 72PSI=1
