Carrier SmartVu control User Manual

SRDC-UG-2-14-000
REVISION
DATE
PAGE
19 Series Carrier®
SmartVu
TM
–
Controls IOM
2.3
Dec 4, 2020
148 OF 168
148
26
coun_cod
0 to 999
86
-
Country Code
27
gv1_type
0 to 1
0
-
Guide Vane1 Type
28
blank
-
-
-
Digital=0, Analog=1
29
dmp_type
0 to 1
0
-
ECO DMP VLV Type
30
blank
-
-
-
Op/Cl=0, Analog=1
31
vfd_fdv
0 to 1
0
-
VFD Feedback Voltage Sel
32
blank
-
-
-
0-5V=0, 0-10V=1
33
hr_opt
0 to 2
0
-
Heat Reclaim Option
34
blank
-
-
-
No=0, Full=1, Partial=2
*Depends on the selected language (English by default).
SERVICE1 - Service Parameters
Name
Range
Default
Unit
Displayed text*
1
atom_pre
55.16 to 103.43
8 to 15
99.98
14.5
kPa
PSI
Atmospheric Pressure
2
gv1_lim
30 to 100
80.7
%
GV1 Travel Limit
3
gv1stpos
0 to 40
4
%
GV1 Closure at Startup
4
max_gv
1 to 4
2
%
Maximum GV Movement
5
ctrl_db
0.28 to 1.11
0.5 to 2
0.56
1
^C
^F
Controlled Fluid DB
6
ewtdgain
1 to 3
2
-
Derivatived EWT Gain
7
gv1decdb
2 to 10
6
-
Proportional Dec Band
8
gv1incdb
2 to 10
6.5
-
Proportional Inc Band
9
dem_20ma
10 to 100
40
%
Demand Limit at 20 mA
10
dem_pdb
3 to 15
10
%
Demand Limit Prop Band
11
ldramprt
5 to 20
5
%
Amps or KW Ramp per Min
