Carrier SmartVu control User Manual

SRDC-UG-2-14-000
REVISION
DATE
PAGE
19 Series Carrier®
SmartVu
TM
–
Controls IOM
2.3
Dec 4, 2020
155 OF 168
155
32
cond_val
3.45 to 344.75
0.5 to 50
344.75
50
kPa
PSI
Cond Hi Flow DP Limit
33
cond_alm
DSABLE_ENABLE
DSABLE
-
Cond Hi Flow Alarm
34
inv_ov
37.78 to 204.44
100 to 400
93.33
200
°C
°F
Inverter Temp Override
*Depends on the selected language (English by default).
CONF_OPT - Option
Name
Range
Default
Unit
Displayed text*
1
astart
DSABLE_ENABLE
ENABLE
-
Auto Restart Option
2
blank
-
-
-
3
swistart
DSABLE_ENABLE
DSABLE
-
Swift Restart Option
4
gt_fact
0.25 to 3
1
-
Gas Torque Factor
5
gv_srd_f
0.7 to 1.2
0.95
-
Guide Vane/SRD Factor
6
pd_tcfg
0 to 60
15
min
Power Recovery Timeout
7
commsens
DSABLE_ENABLE
DSABLE
-
Common Sensor Option
8
hgbp_opt
0 to 3
0
-
EC/HG Valve Option
9
blank
-
-
-
No=0, Cont.=1,
10
blank
-
-
-
ON/OFF=2, mA=3
11
hgbp_sel
0 to 3
0
-
EC/HG Valve Selection
12
blank
-
-
-
Disable=0, Surge=1
13
blank
-
-
-
Low Load=2, Comb=3
14
hpop_gv1
0.5 to 10
5
%
EC/HG VLV Open IGV1 Pos
15
hgcl_gv1
1.5 to 35
10
%
EC/HG VLV Close IGV1 Pos
16
hgbp_ldb
0.28 to 1.11
0.5 to 2
0.56
1
^C
^F
EC/HG VLV Low Load DB
