Carrier SmartVu control User Manual

SRDC-UG-2-14-000
REVISION
DATE
PAGE
19 Series Carrier®
SmartVu
TM
–
Controls IOM
2.3
Dec 4, 2020
156 OF 168
156
17
hdpv_opt
DSABLE_ENABLE
DSABLE
-
HPR VLV Option
18
hdp_0
0.00 to 586.08
0 to 85
172.38
25
kPa
PSI
HPR VLV Delta Pos 0%
19
hdp_100
0.00 to 586.08
0 to 85
344.75
50
kPa
PSI
HPR VLV Delta Pos 100%
20
hdpv_min
0 to 100
0
%
HPR VLV Min Output
21
hdpv_db
0.00 to 68.95
0 to 10
6.90
1
kPa
PSIG
HPR VLV Deadband
22
tfh_sp
12.78 to 40.56
55 to 105
23.89
75
°C
°F
Tower Fan High Setpoint
23
leak_en
DSABLE_ENABLE
DSABLE
-
Refrig Leakage Option
24
leak_ma
4 to 20
20
mA
Refrig Leakage Alarm mA
25
exv_opt
DSABLE_ENABLE
DSABLE
-
Oil Cooler EXV Option
26
oil_high
37.78 to 60.00
100 to 140
50.00
122
°C
°F
Oil Temp High Threshold
27
oil_low
32.22 to 54.44
90 to 130
45.00
113
°C
°F
Oil Temp Low Threshold
28
cusa_opt
DSABLE_ENABLE
DSABLE
-
Customer Alert Option
29
ice_opt
DSABLE_ENABLE
DSABLE
-
Ice Build Option
30
ice_recy
DSABLE_ENABLE
DSABLE
-
Ice Build Recycle
31
ice_term
0 to 2
0
-
Ice Build Termin Source
32
blank
-
-
-
Temp=0,Contact=1,Both=2
33
opvfdmax
241.33 to 413.70
35 to 60
344.75
50
kPa
PSI
Oil Pump VFD Max PD
34
opvfdstp
0 to 10
7
%
Oil Pump VFD Max Step
35
vssv_opt
DSABLE_ENABLE
DSABLE
-
Vapor Source SV Option
