Carrier SmartVu control User Manual

SRDC-UG-2-14-000
REVISION
DATE
PAGE
19 Series Carrier®
SmartVu
TM
–
Controls IOM
2.3
Dec 4, 2020
161 OF 168
161
12
dis_wt
0 to 40
1
min
PG Discharge Wait Time
13
pgpumplm
20 to 200
50
min
Daily PG Pumpout Limit
14
mot_pol
1 to 2
1
-
Motor Pole Pair
15
blank
-
-
-
Single=1, Double=2
16
gv2_lim
30 to 100
96
%
IGV2 Travel Limit
17
gv2_dmin
0 to 20
2
-
IGV2 Minimum Degree
18
gv2_dful
10 to 100
90
-
IGV2 Full Load Open Deg
19
gv2_dmax
90 to 120
94
-
IGV2 Actuator Max Deg
20
gv2_d20
10 to 30
28.1
-
IGV2 Deg @IGV1 20 Deg
21
gv2_d30
10 to 50
37.2
-
IGV2 Deg @IGV1 30 Deg
22
gv2_d50
10 to 80
71.6
-
IGV2 Deg @IGV1 50 Deg
23
vfd_ratf
10 to 200
80.5
Hz
Comp Based Speed Hz
24
lega_lub
DSABLE_ENABLE
DSABLE
-
4-valve Lube(Legacy DV4)
25
opt_7
DSABLE_ENABLE
DSABLE
-
Pre Lube from Colder HX
26
brg_th
0.00 to 206.85
0 to 30
55.16
8
kPa
PSI
Bearing Press Thresholds
27
blank
-
-
-
(Only for Legacy DV4)
*Depends on the selected language (English by default).
CFGGEVFD - General VFD
Name
Range
Default
Unit
Displayed text*
1
comp_100
45 to 500
50
Hz
Comp Frequency 100%
2
vfd_gain
0.1 to 1.5
0.75
-
VFD Gain
3
vfd_max
90 to 110
100
%
VFD Max Speed Per
4
vfd_min
45 to 100
70
%
VFD Min Speed Per
5
vfd_str
65 to 100
100
%
VFD Startup Speed Per

Carrier SmartVu control Specifications

General

Brand	Carrier
Model	SmartVu control
Category	Control Panel
Language	English
