Carrier SmartVu control User Manual

SRDC-UG-2-14-000
REVISION
DATE
PAGE
19 Series Carrier®
SmartVu
TM
–
Controls IOM
2.3
Dec 4, 2020
23 OF 168
23
IOB1
DO4
Chiller Status(Discrete)
user option
，
0=chiller off,
1=chiller running
IOB2
AI1
Motor Winding Temperature 1
IOB2
AI2
Motor Winding Temperature 2
IOB2
AI3
Motor Winding Temperature 3
IOB2
AI4
Oil Supply Temperature
IOB2
AI5
Oil Sump Temperature
IOB2
AI6
Oil Supply Pressure
IOB2
AI7
Oil Sump Pressure
IOB2
AI8
Auto Demand Limit Input
User option
IOB2
AI9
EC Valve Feedback
IOB2
AI10
Bearing Shaft Displacement Sensor
IOB2
AI11
IOB2
AO1
Guide Vane1 Output
Used for Analog type
guide vane actuator
IOB2
AO2
Damper Valve Output mA
For analog type damper
valve
IOB2
AO3
EC Valve Output mA
IOB2
DI1
Damper Valve Feedback Fully Open
For digital type damper
valve
IOB2
DI2
Damper Valve Feedback Fully Close
For digital type damper
valve
IOB2
DI3
High Pressure Switch
0=abnomal ,1=close
IOB2
DI4
[If ISM Input is disable]
Ice Build Contact
User option
IOB2
DO1
Oil Heater Relay
IOB2
DO2
Oil Pump Relay
IOB2
DO3
[If vapor source valve is disabled]
Economizer Damper Valve Open
IOB2
DO4
[If vapor source valve is disabled]
Economizer Damper Valve Close
[If vapor source valve is enabled]
Vapor Source SV
For digital type damper
valve
For vapor source valve
IOB3
AI1
Low Speed ME Brg Temp
IOB3
AI2
Low Speed CE Brg Temp
IOB3
AI3
High Speed ME Brg Temp
IOB3
AI4
High Speed CE Brg Temp
IOB3
AI5
Remote Reset Sensor
User option
