Carrier SmartVu control User Manual

SRDC-UG-2-14-000
REVISION
DATE
PAGE
19 Series Carrier®
SmartVu
TM
–
Controls IOM
2.3
Dec 4, 2020
24 OF 168
24
IOB3
AI6
[If guide vane1 Type is Analog]
GV1 Pos Feedback
[If guide vane1 Type is Digital]
Guide Vane 1 Actual Ohms
For analog type guide
vane
For digital type guide vane
IOB3
AI7
[If Common Sensor Option is enable]
Common CHWS Temp
Used for lead lag option
IOB3
AI8
Auto Water Temp Reset
User option
IOB3
AI9
[If Common Sensor Option is enable]
Common CHWR Temp
Used for lead lag option
IOB3
AI10
Dample Valve Feedback
For analog type damper
valve
IOB3
AI11
IOB3
AO1
Head Pressure Output
User option
IOB3
AO2
Head Pressure Output 2
User option
IOB3
AO3
IOB3
DI1
EC Valve Feedback Fully Open
Used for Continues or
ON/OFF type HGBP valve
IOB3
DI2
EC Valve Feedback Fully Close
Used for Continues or
ON/OFF type HGBP valve
IOB3
DI3
Spare Safety
User option, normal open
IOB3
DI4
IOB3
DO1
EC Valve Solenoid / Open
Used for Continues or
ON/OFF type HGBP valve
IOB3
DO2
EC Valve Close
Used for Continues or
ON/OFF type HGBP valve
IOB3
DO3
Chilled Water Pump
User option
IOB3
DO4
Condenser Water Pump
User option
IOB4
AI1
Heat Reclaim Entering Temp
User Option
IOB4
AI2
Heat Reclaim Leaving Temp
User Option
IOB4
AI3
[If Water Pressure Option is PD TRD
(transducers)]
Evap Enter Water Volts
[If Water Pressure Option is PD TRM
(transmitter)]
Chilled Water Pres Drop
User option, if IOB4
installed, same as follows
IOB4
AI4
[If Water Pressure Option is PD TRD
(transducers)]
Evap Leave Water Volts
User option
