Carrier SmartVu control User Manual

SRDC-UG-2-14-000
REVISION
DATE
PAGE
19 Series Carrier®
SmartVu
TM
–
Controls IOM
2.3
Dec 4, 2020
25 OF 168
25
[If Water Pressure Option is PD TRM
(transmitter)]
Cond Water Pres Drop
IOB4
AI5
[If Water Pressure Option is PD TRD
(transducers)]
Cond Enter Water Volts
User option
IOB4
AI6
[If Water Pressure Option is PD TRD
(transducers)]
Leaving Cond Water Pressure
User option
IOB4
AI7
Refrigerant Leak Sensor
User option
IOB4
AI8
Evap Water Flow Measurement
User option
IOB4
AI9
Cond Water Flow Measurement
User option
IOB4
AI10
IOB4
AI11
IOB4
AO1
IOB4
AO2
IOB4
AO3
IOB4
DI1
IOB4
DI2
Power Request Feedback
Marine option
IOB4
DI3
Customer Alert
User option
IOB4
DI4
Free Cooling Start Switch
User option
IOB4
DO1
Free Cooling Mode
User option
IOB4
DO2
Power Request Output
Marine option
IOB4
DO3
Tower Fan High
User option
IOB4
DO4
Tower Fan Low
User option
19XR2~5/C/D/E/V I/O mapping：
For 19XR2~5/C/D/E/V IOB1/2 is standard and IOB3/4 is optional.
Board #
Channel #
Description
Comments
IOB1
AI1
Entering Chilled Water Temperature
IOB1
AI2
Leaving Chilled Water Temperature
IOB1
AI3
Entering Condenser Water Temperature
IOB1
AI4
Leaving Condenser Water Temperature
IOB1
AI5
[If Evap Liquid Temp Opt is enable]
Evap. Refrigerant Liquid Temperature
IOB1
AI6
Comp Discharge Temperature
IOB1
AI7
Condenser Pressure
IOB1
AI8
Evaporator Pressure
IOB1
AI9
Economizer Pressure
