Carrier SmartVu control User Manual

SRDC-UG-2-14-000
REVISION
DATE
PAGE
19 Series Carrier®
SmartVu
TM
–
Controls IOM
2.3
Dec 4, 2020
30 OF 168
30
IOB2
AI2
Condenser Refrigerant Vapor Temperature
Standard for DV5
IOB2
AI3
EC Valve Feedback
Used for mA type
HGBP valve
IOB2
AI4
IOB2
AI5
Pump Outlet Pressure
IOB2
AI6
Bearing Outlet Pressure
IOB2
AI7
Bearing Inlet Pressure
IOB2
AI8
Auto Demand Limit Input
User option
IOB2
AI9
Refrigerant Leak Sensor
User option
IOB2
AI10
Pump Inlet Pressure
IOB2
AI11
IOB2
AO1
Guide Vane1 Output
IOB2
AO2
IOB2
AO3
EC Valve Output mA
IOB2
DI1
IOB2
DI2
Liquid Level Switch
0=low liquid level,
1=high loquid leve
IOB2
DI3
High Pressure Switch
0=abnomal ,1=close
IOB2
DI4
[If ISM Input is disable]
Ice Build Contact
User option, dry
contact
IOB2
DO1
Condenser Control Valve
IOB2
DO2
Evaporator Control Valve
IOB2
DO3
Danfoss VFD Interlock
Standard for Dnfoss
VFD,0=VFD Operation
forbidden,1=Operation
enabled
IOB2
DO4
Economizer Isolation Valve
IOB3
AI1
1st Stage Bearing Temp
IOB3
AI2
2nd Stage Bearing Temp
IOB3
AI3
IOB3
AI4
Guide Vane 2 Actual Pos
IOB3
AI5
Remote Reset Sensor
User option
IOB3
AI6
Guide Vane 1 Actual Pos
IOB3
AI7
[If Common Sensor Option is enable]
Common CHWS Temp
Used for lead lag
option
IOB3
AI8
Auto Water Temp Reset
User option
IOB3
AI9
[If Common Sensor Option is enable]
Common CHWR Temp
Used for lead lag
option
IOB3
AI10
IOB3
AI11
