Carrier SmartVu control User Manual

SRDC-UG-2-14-000
REVISION
DATE
PAGE
19 Series Carrier®
SmartVu
TM
–
Controls IOM
2.3
Dec 4, 2020
31 OF 168
31
IOB3
AO1
Head Pressure Output
User option
IOB3
AO2
Head Pressure Output 2
User option
IOB3
AO3
Guide Vane 2 Output
IOB3
DI1
IOB3
DI2
IOB3
DI3
Spare Safety
User option, normal
open
IOB3
DI4
IOB3
DO1
[If 4-valve lub (legacy DV4) is enabled]
Evaporator Drain Valve
[If 4-valve lub (legacy DV4) is disabled]
Chiller Status(Discrete)
IOB3
DO2
Condenser Drain Valve
Standard for 4 valve
lub
IOB3
DO3
Chilled Water Pump
User option
IOB3
DO4
Condenser Water Pump
User option
IOB4
AI1
IOB4
AI2
IOB4
AI3
[If Water Pressure Option is PD TRD
(transducers)]
Evap Enter Water Volts
[If Water Pressure Option is PD TRM (transmitter)]
Chilled Water Pres Drop
User option
IOB4
AI4
[If Water Pressure Option is PD TRD
(transducers)]
Evap Leave Water Volts
[If Water Pressure Option is PD TRM (transmitter)]
Cond Water Pres Drop
User option
IOB4
AI5
[If Water Pressure Option is PD TRD
(transducers)]
Cond Enter Water Volts
User option
IOB4
AI6
[If Water Pressure Option is PD TRD
(transducers)]
Leaving Cond Water Pressure
User option
IOB4
AI7
IOB4
AI8
Evap Water Flow Measurement
User option
IOB4
AI9
Cond Water Flow Measurement
User option
IOB4
AI10
