Carrier SmartVu control User Manual

SRDC-UG-2-14-000
REVISION
DATE
PAGE
19 Series Carrier®
SmartVu
TM
–
Controls IOM
2.3
Dec 4, 2020
32 OF 168
32
IOB4
AI11
IOB4
AO1
IOB4
AO2
IOB4
AO3
IOB4
DI1
IOB4
DI2
Power Request Feedback
Marine option
IOB4
DI3
Customer Alert
User option
IOB4
DI4
Free Cooling Start Switch
User option
IOB4
DO1
Free Cooling Mode
User option
IOB4
DO2
Power Request Output
Marine option
IOB4
DO3
Tower Fan High
User option
IOB4
DO4
Tower Fan Low
User option
SIOB
cDI-01
Purge Level Switch Low
0= lower than low
level,1=higher than low
level
SIOB
cDI-02
Purge Level Switch High
0= lower than high
level,1=higher than
high level
SIOB
AI-01
Purge Comp Suction Temp
SIOB
DO-01
Purge Cond Valve
SIOB
DO-02
Purge Comp Valve
SIOB
DO-03
Purge Pumpout Valve
SIOB
DO-04
Purge Drainage Valve
SIOB
cDO-05
Purge Regeneration Valve
SIOB
cDO-06
Purge Discharge Valve
SIOB
DO-07
Purge Vaccum Pump
SIOB
DO-08
Purge Compressor
SIOB
DO-09
Purge Drainage Idle VLV
SIOB
DO-10
Purge Heater
19XRF I/O mapping：
For 19XRF IOB1/2 is standard and IOB3/4 is optional.
Board #
Channel
#
Description
Comments
IOB1
AI1
Entering Chilled Water Temperature
IOB1
AI2
Leaving Chilled Water Temperature
IOB1
AI3
Entering Condenser Water Temperature
IOB1
AI4
Leaving Condenser Water Temperature
