Carrier SmartVu control User Manual

SRDC-UG-2-14-000
REVISION
DATE
PAGE
19 Series Carrier®
SmartVu
TM
–
Controls IOM
2.3
Dec 4, 2020
33 OF 168
33
IOB1
AI5
[If Evap Liquid Temp Opt is enable]
Evap. Refrigerant Liquid Temperature
IOB1
AI6
Comp Discharge Temperature
IOB1
AI7
Condenser Pressure
IOB1
AI8
Evaporator Pressure
IOB1
AI9
EC Valve Feedback
IOB1
AI10
FS VFD Load Current
For free standing VFD
IOB1
AI11
IOB1
AO1
Chiller Status (Analog)
User option, 4~20mA
4mA=OFF
8mA=Tripout
12mA=Shutdown
20mA=Running
IOB1
AO2
Oil EXV Output
IOB1
AO3
EC Valve Output mA
IOB1
DI1
Chiller Lockout Input
User option,normal
open
IOB1
DI2
Spare Safety
User option,normal
open
IOB1
DI3
[If ISM Input is disable]
Remote Contact Input
User option, “Closed”
indicates Turn ON the
chiller
IOB1
DI4
[If ISM Input is disable]
Remote Emergency Stop Input
User option, “Closed”
indicates chiller
emergency stop
IOB1
DO1
Chilled Water Pump
User option
IOB1
DO2
Condenser Water Pump
User option
IOB1
DO3
Chiller Alarm Relay
User option, 24VAC
output, recommend
with external power
supply
IOB1
DO4
Danfoss VFD Interlock
IOB2
AI1
Economizer Pressure
IOB2
AI2
High Speed CE Brg Temp
IOB2
AI3
Oil Sump Temperature
IOB2
AI4
Oil Supply Temperature
IOB2
AI5
[If guide vane1 Type is Analog]
GV1 Pos Feedback
[If guide vane1 Type is Digital]
Guide Vane 1 Actual Ohms
For analog type guide
vane
For digital type guide
vane
IOB2
AI6
Oil Supply Pressure
IOB2
AI7
Oil Sump Pressure
IOB2
AI8
Motor Winding Temperature 1
IOB2
AI9
Motor Winding Temperature 2
