Carrier SmartVu control User Manual

SRDC-UG-2-14-000
REVISION
DATE
PAGE
19 Series Carrier®
SmartVu
TM
–
Controls IOM
2.3
Dec 4, 2020
34 OF 168
34
IOB2
AI10
Motor Winding Temperature 3
IOB2
AI11
IOB2
AO1
Guide Vane1 Output
Used for Analog type
guide vane actuator
IOB2
AO2
Head Pressure Output 2
User option
IOB2
AO3
Head Pressure Output
User option
IOB2
DI1
Evap Water Flow Switch
User option, “Closed”
indicates “FLOW”
IOB2
DI2
Cond Water Flow Switch
User option,“Closed”
indicates “FLOW”
IOB2
DI3
High Pressure Switch
IOB2
DI4
IOB2
DO1
Oil Heater Relay
IOB2
DO2
Oil Pump Relay
IOB2
DO3
Chiller Status(Discrete)
user option，0=chiller
off, 1=chiller running
IOB2
DO4
Vapor Source SV
IOB3
AI1
IOB3
AI2
IOB3
AI3
Heat Reclaim Entering Temp
IOB3
AI4
Heat Reclaim Leaving Temp
IOB3
AI5
Remote Reset Sensor
User option
IOB3
AI6
Auto Water Temp Reset
User option
IOB3
AI7
[If Common Sensor Option is enable]
Common CHWS Temp
Used for lead lag
option
IOB3
AI8
Auto Demand Limit Input
User option
IOB3
AI9
[If Common Sensor Option is enable]
Common CHWR Temp
Used for lead lag
option
IOB3
AI10
Refrigerant Leak Sensor
User option
IOB3
AI11
IOB3
AO1
IOB3
AO2
IOB3
AO3
IOB3
DI1
Fire Security Interlock
User option,normal
open
IOB3
DI2
[If ISM Input is disable]
Ice Build Contact
User option
IOB3
DI3
IOB3
DI4
IOB3
DO1
IOB3
DO2
Chiller Alert Relay
User option, 24VAC
output, recommend
with external power
supply
