TEST 7
Function: BCD Output Test
Key Used Display Description
: Upper Menu
: ON/OFF Switch
OFF
ON
ALL ON：All BCD Outputs are ON
ALL OFF：All BCD Outputs are OFF
TEST 8
Function: ANALOG Output Test (0-24mA, 0-10V)
Key Used Display Description
: Upper Menu
: HIGH/ZERO Switch
HIGH
ZERO
HIGH: Outputs the value of the Maximum
Weight.
ZERO: Outputs the value of Zero.
Note 1. Press key during Test 8 to repeat ANALOG Output of ZERO/HIGH.
Note 2. The value of ZERO/HIGH is outputted as the values set in F71 and F72.
Note 3. Use 1~5 keys to run the output test of the default values.
(In case of setting the Analog Output Card as 0~24mA)
#1 key: 0.00mA, #2 key: 6.00mA , #3 key: 12.00mA
#4 key: 18.00mA , #5 key: 24.00mA will be outputted.
