37
Set-up for the External relay In/Output Function(Relay Function)
F50 (06) Set-up for the external relay input Set 7 types of external relay input
F51 (1) Select the Weighing Mode (1~9) 9 types of Weighing Mode
F52 (10)
Delay time of
Finish relay output (0~ 9.9)
0 sec ~ 9.9 sec
F53 (10)
Delay time of Finish relay operation
(0.0 ~ 9.9)
0 sec ~ 9.9 sec
F54 (10)
Delay time of judgment-relay output
(0.0 ~ 9.9)
0 sec ~ 9.9 sec
F55 (10)
Delay time of judgment-relay
operation (0.0 ~ 9.9)
0 sec ~ 9.9 sec
F56 (10)
Operation time of weighing NG
Relay Output (0.0 ~ 9.9)
0 sec ~ 9.9 sec
F57 (02)
Set-up for the near Zero (Empty)
range(00 ~ 99)
Set near Zero in a range of 00~99
division units
Additional Set-up Functions
F60 (00) Set the Forced Zero Range (00~99)
00: Do not use
99: Automatic Zero if the indicated
weight is below 99
F61 (00) Hold OFF Time (0.0~9.9) 0.0 sec ~ 9.9 sec
F62 (0) Designate the Code Number (0~2)
Fixed / after 1 time of weighing
increase by 1 / decrease by 1
F63 (0)
RS-232C Communication
Set the STREAM rate (0~9)
16 times / sec ~ 1 time / sec
F64 (0) Set the Maximum Hold Range (0~1)
0: When the weight is ‘0’, automatic hold
function is cleared
1: (+) range, (-) range all available
F65 (0)
Indicate time when the weight is ‘0’
(0~1)
0: Do not indicate time
1: Indicate time
F66 (0)
Change all of Step1~4
according to the ID number (0~1)
Not applied / Applied
F67 (0)
Indicate the Gross Weight in the step
1 Window when tarring off.
Do not indicate / Indicate
