39
General Function
F01
Function Set-up for the Weighing Unit (Weighing Unit)
Display Signification
F01. 0 Kilogram (kg)
F01. 1 Gram (g)
Set-up Range
(0, 1)
F01. 2 Ton (t)
F02
Function Set-up for the Load Cell Type (Tension or Compress, Tension & Compression)
Display Signification
F02. 0 Load cell in compression type or tension type
Set-up Range
(0, 1)
F02. 1
Load cell in both compression and tension type
* When A_UP S/W3 is ON, the value of Zero increases
F03
Function Set-up for the weight indication rate ( FND display indication rate)
Display Signification Display Signification
F03. 0 200 times / sec F03. 5 16 times / sec
F03. 1 100 times / sec F03. 6 18 times / sec
F03. 2 80 times / sec F03. 7 4 times / sec
F03. 3 64 times / sec F03. 8 2 times / sec
Set-up Range
(0 ~ 9)
F03. 4 32 times / sec F03. 9 1 time / sec
F04
Function Set-up for the Digital Filter
Display Signification
Set-up Range
(1 ~ 49)
F04. 1 ~ 49
1: Places with low levels of vibration
~ 49: Places with high levels of vibration
25 in case of general weighing operation
F05
Function Set-up for the Stability Condition of weight
Display Signification
F05. 0
Stable lamp is on if there is a variation in weight within 0.5
divisions in the designated time.
F05. 5
Stable lamp is on if there is a variation in weight within 2.5
divisions in the designated time.
Set-up Range
(0 ~ 9)
F05. 9
Stable lamp is on if there is a variation in weight within 5
divisions in the designated time.
Note 1. This function recognizes it as stable if the variation in weight does not exceed the set range of A/D
Count within the designated time. If the Indicator is located in a place with high levels of vibration,
then increase the number, and if the Indicator is located in a place with low levels of vibration,
then decrease the number in order to quickly reach stability in weight measurement.
