7
8
2. BCC (Check-Sum) not used. (Set F25 – 04)
TO →
INDICATOR
Command Description Indicator Response
STX ID. NO.
WZER ETX
Command to set “ZERO”
TX ID. NO. WZER ACK ETX
or
STX ID. NO. WZER NAK ETX
▶ Format when Commanded by PC
STX(1) ID.NO.(2) COMMAND(4) ETX(1)
STX ID.NO. WZER ETX
2H 30H 31H 57H 5AH 45H 52H 03H
● ID.NO. : F20 Set Device Number = 01(30H 31H)
▶ Indicator Data Transmission Format
STX(1) ID.NO.(2) COMMAND(4) ACK(1) ETX(1)
STX ID.NO. WZER ACK ETX
2H 30H 31H 57H 5AH 45H 52H 06H 03H
● ACK : 06H = Transmission Complete (Normal Operation) , NAK : 15H Transmission
Unsuccessful (Re-transmit)
▶ COMMAND MODE ( READ COMMAND )
TO →
INDICATOR
Command Description Indicator Response
STX ID. NO. RTIM
BCC(9D) ETX
Command to transmit the
Indicator’s TIME DATA
Transmit TIME DATA (6)
- STX ID.NO. RTIM 000000 BCC ETX
STX ID. NO. RDAT
BCC(8C) ETX
Command to transmit the
Indicator’s DATE DATA
Transmit DATE DATA (6)
- STX ID. NO. RDAT 000000 BCC ETX
STX ID. NO. RSNO
BCC(A3) ETX
Command to transmit the
Serial Number
Transmit S/N (6)
- STX ID. NO. RSNO 000000 BCC ETX
STX ID. NO. RCNO
BCC(93) ETX
Command to transmit the
Code Number
Transmit Code Number (6)
- STX ID. NO. RCNO 000000 BCC ETX
STX ID. NO. RPNO
BCC(A0) ETX
Command to transmit the Part
Number
Transmit P/N (2)
- STX ID. NO. RPNO 00 BCC ETX
STX ID. NO. RTAR
BCC(9A) ETX
Command to transmit the
weight value of “KEY Tare”
Transmit KEY Tare (6)
- STX ID. NO. RTAR 000000 BCC ETX
STX ID. NO. RCWT
BCC(A1) ETX
Command to transmit the
“Current Weight Value”
Transmit the “Current Weight Value”
- STX ID. NO. RCWT DATA1
BCC ETX
STX ID. NO. RSUB
BCC(9D) ETX
Command to transmit the
“Sub-total”
- STX ID. NO. RSUB P/N(2) CODE(6)
COUNT(6) S.T.W(8)
BCC ETX
No Decimal Place
STX ID. NO. RGRD
BCC(90) ETX
Command to transmit the
“Grand-Total”
- STX ID.NO. RGRD P/N(2) CODE(6)
T_COUNT(6) G.T.W(10)
BCC ETX
No Decimal Place
STX ID. NO. RFIN
BCC(90) ETX
Command to transmit the
Weighing Completion Value
Transmit the Weighing Completion Value
- STX ID. NO. RFIN RN( Weight of 6 digit)
BCC ETX
STX ID. NO. RCWD
BCC(91) ETX
Command to transmit the all
the current data stored in the
Indicator
Transmit the all the “current weight”
- STX ID. NO. RCWD DATA2
BCC ETX
