CAS CI-502A - Page 78

`
79
STX ID. NO.
RSP1 BCC ETX
Command to transmit the DATA of
the Step 1
Transmit the Step 1 DATA (6)
- STX ID.NO. RSP1 000000 BCC ETX
STX ID. NO.
RSP2 BCC ETX
Command to transmit the DATA of
the Step 2
Transmit the Step 2 DATA (6)
- STX ID.NO. RSP2 000000 BCC ETX
STX ID. NO.
RSP3 BCC ETX
Command to transmit the DATA of
the Step 3
Transmit the Step 3 DATA (6)
- STX ID.NO. RSP3 000000 BCC ETX
STX ID. NO.
RSP4 BCC ETX
Command to transmit the DATA of
the Step 4
Transmit the Step 4 DATA (6)
- STX ID.NO. RSP4 000000 BCC ETX
STX ID. NO.
RUND BCC ETX
Command to transmit the DATA of
the lowest limit
Transmit the DATA of the lowest limit (4)
- STX ID.NO. RUND 0000 BCC ETX
STX ID. NO.
ROVE BCC ETX
Command to transmit the DATA of
the upper limit
Transmit the DATA of the upper limit (4)
- STX ID.NO. ROVE 0000 BCC ETX
DATA1 (16)※
1. Header1
ST = Stable, US = Unstable, OL = Over Load
2. Header2
NT = Net Weight , GS = Gross Weight
3. DATA
Weight including code and decimals
4. UNIT
Kg = kg, t = t, g = g
D※ ATA2 (38)
STX
(1)
ID.NO
(2)
COMMAND
(4)
DATA
(16)
BCC
(2)
ETX
(1)
Header1
(2)
,(1)
Header2
(2)
,(1) DATA (8) UNIT (2)
DATE (6) TIME (6) P/N (2)
CODE
(6)
S/N
(6)
KEY TARE
(6)
Current
Weight
(6)
