(2) Errors that can occur in Weight Calibration Mode
ERROR 31
▣ Reason for Error
The set resolution exceeds the allowed resolution value,
1/50,000.
☞ Troubleshoot
Lower the resolution. Resolution = Maximum weight / 1 division unit value. Modify
the maximum weight in CAL 1 of the Weight Calibration Menu or modify the division
unit value in CAL 2 of the Weight Calibration Menu to lower the resolution below
1/50,000.
ERROR 32
▣ Reason for Error
The balance weight for Span Calibration is set to less than 2% of the scale's full
capacity or exceeds it.
☞ Troubleshoot
Set the balance weight for Span Calibration in between 2~100% of the scale's full
capacity in CAL 3 of the Weight Calibration Menu.
ERROR 33
▣ Reason for Error
The output value of the load cell is too low. Span is too low.
☞ Troubleshoot
There is a problem in the load cell or the load cell's output is too low. With the current
output from the load cell, Weight Calibration cannot be carried out.
If in Zero Calibration, place a cover on the scale.
If in Weight Calibration, set a heavier balance weight.
ERROR 34
▣ Reason for Error
The output value of the load cell is too high. Span is too high.
☞ Troubleshoot
There is a problem in the load cell or the load cell's output is too high. With the current
output from the load cell, Weight Calibration cannot be carried out. If in Zero
Calibration, remove the item from the scale. If in Calibration, place a lighter balance
weight on the scale.
If this message appears even when the scale is empty, contact the A/S department of our
company.
