Casio TE-2400 Service Manual

CONTENTS
TE-2200/2400 PAGE
1. SPECIFICATIONS........................................................................................ 1
2. MACHINE INITIALIZATION ......................................................................... 4
3. DISASSEMBLY ............................................................................................ 7
4. CIRCUIT EXPLANATION .......................................................................... 17
5. DIAGNOSTIC OPERATION ....................................................................... 29
6. ERROR CODE LIST................................................................................... 55
7. IC DATA ..................................................................................................... 59
8. PCB LAYOUT ............................................................................................ 66
9. CIRCUIT DIAGRAMS................................................................................. 68
10. PARTS LIST ............................................................................................... 82
To prevent malfunctions caused by the weak batteries, charge the memory
protection batteries for over 12-hours before installation or after a long-time
vacation (over 30 days).
• Before installation, initialize the terminal and leave it turn on over 12-hours.
• After a long-time vacation, initialize the terminal and restore the program data if
the terminal is in malfunction, and leave it turn on over 12-hours.
• Over 48-hours charging makes the batteries fully charged.

Casio TE-2400 Specifications

General

Types of payment	Cash
Supported paper width	58 mm
Display digits	10 digits
Second display	Yes
Second display type	LED
Display number of characters	16
Power source	AC
AC input voltage	120-230 V
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth	450 mm
Width	400 mm
Height	277 mm
Weight	12000 g
