Casio TE-2400 Service Manual

— 38 —
[ 12 ] Display test
[Function]
LCD, Pop-up display and transaction display tests are performed (as follows).
[Pop-up display] [Main display]
Input command

Pattern 1

Pattern 2

End
[Operation]
Operation : n 0 2 1 SUBTOTAL
n : 0 = One time check (can be omitted)
not 0 = Continuous check (To stop the test, press “C” key)
* Any key must be pressed to end the test when performing one time check.
[PRINT]
Press any key
Press any key
8.8.8.8.8.8.8.8.
3 4 5 6 7 8 9 0
DIAG 1
8888888888
,,,,,,,,,,
ABCDEFGH I JKLMNOP
QRSTUVWXYZabcde f
1234567890
DISP 21
DISP OK
END 21

Casio TE-2400 Specifications

General

Types of payment	Cash
Supported paper width	58 mm
Display digits	10 digits
Second display	Yes
Second display type	LED
Display number of characters	16
Power source	AC
AC input voltage	120-230 V
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth	450 mm
Width	400 mm
Height	277 mm
Weight	12000 g
