— 51 —
[ 28 ] Consumption current
[Function]
Connect LCD, REAR, DISP, OBR, and DRW then perform the test as follows.
All Pop-up display and Main display turn on. Repeat printing in the internal printer.
[Operation]
Operation : 1 9 3 SUBTOTAL
Press “C” key or turn off the power to stop.
[Pop-up display]
[Main display]
8.8.8.8.8.8.8.8.
DIAG 193
8888888888
,,,,,,,,,,
Print pattern image
[Print]
Prints only in the receipt of the internal printer
with 50% dot rate.
