Casio TE-2400 Service Manual

— 54 —
[ 31 ] Displaying the battery voltage
[Function]
Display the battery voltage. Display with three digits.
Example : “300” indicates “3.00” v.
[Operation]
Operation : 9 6 SUBTOTAL
Press “C” key or turn off the power to stop the test.
[Pop-up display]
xxx : battery voltage
[Main display]
xxx : battery voltage
[Print]
No printing in this test.
x.8.8.8.8 x x x
DIAG 96
xxx

Casio TE-2400 Specifications

General

Types of payment	Cash
Supported paper width	58 mm
Display digits	10 digits
Second display	Yes
Second display type	LED
Display number of characters	16
Power source	AC
AC input voltage	120-230 V
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth	450 mm
Width	400 mm
Height	277 mm
Weight	12000 g
