Casio TE-2400 - Keyboard Block; Power Supply Block; Rear Display Block

— 93 —
N Item Code No. Parts Name S
p
ecification R
10204342 Connector IMSA-9632S-16Y917 1 1 1 AC X
10204343 Connector IMSA-9610S-10Y918 1 1 1 AD X
10204344 Connector IMSA-9610S-12Y918 1 1 1 AD X
10211994 LCD cable sub assy RJE501494*001V02 1 1 1 AP C
4 10203339 DP case RJE501455-002V01 1 1 1 BC X
5 10224742 DP board RJE501547-002V01 1 1 1 AX C
6 10104622 RDP bush RJE500339-001V01 1 1 1 AC X
10126583 LCD cushion V RJE500659-001V01 2 2 2 AB C
10126584 LCD cushion H RJE500659-002V01 2 2 2 AB C
7 10207417 LCD stand R RJE501418-001V01 1 1 1 AI X
8 10207418 LCD stand L RJE501419-001V01 1 1 1 AI X
for USA,Canada
10204353 E443-LED assy RJE501488*001V01 1 1 DB A
10072597 LED HDSP-521G 5 5 AN A
10072598 LED HDSP-A22G 4 4 AX A
10136132 LED HLMP-S501 9 9 AC A
10204339 Connector IMSA-9610S-20B-TC 1 1 AE X
10204344 Connector IMSA-9610S-12Y918 1 1 AD X
10204343 Connector IMSA-9610S-10Y918 1 1 AD X
10210576 LED holder RJE501462-002V01 1 1 AC X
10295606 IC ULN2003ADR 7 7 AF B
10005662 IC SN74LV374APWR 7 7 AF B
22501603 Transistor 2SB1182TLQR 4 4 AC B
10120138 Transistor 2SA2018-TL 1 1 AC B
22592674 Transistor DTC114YETL 5 5 AA B
4,5 10224258 DP board (with DP case) RJE501524-001V02 1 1 BA C
10224257 Blind sheet C RJE501567-001V01 1 1 AB X
7 10207415 DP mount R RJE501586-001V01 1 1 AG X
8 10207416 DP mount L RJE501587-001V01 1 1 AG X
3. Rear Dis
p
la
y
Bloc
k
10211985 RDP-assy RJE501542*002V01 1 1 1
10211988 RDP-assy RJE501542*003V01 1 1 BY
9 10094111 Rear Display case E140466-001V02 1 1 AF X
9 10211989 Rear Display case RJE501565-001V01 1 1 1 AM X
10 10072602 Rear display plate E140465-1 1 1 1 1 1 AF B
11 10204322 E443-E22 assy RJE501484*001V01 1 1 1 1 1 BV A
12 10211991 FFC joiner A RJE501553-001V01 1 1 1 1 1 AE B
13 10211990 FFC joiner B RJE501553-002V01 1 1 1 1 1 AF B
14 10211992 Cushion R RJE501554-001V01 2 2 2 2 2 AA C
4. Ke
y
board Blo
c
15
10224262
Sheet cover
RJE501533-001V02
1 1 1 1 1 BF
A
16
10210649
Menu sheet
RJE501535-003V01
11 1
AA
X
16
10211506
Menu sheet
RJE501535-005V01
11
AA
X
17
10207520
No slip sheet
RJE501534-001V01
1 1 1 1 1 BO C
18
10224264
KB Frame
RJE501445-001V03
1 11 1 1
A
O
X
19
10207401
Contact rubber
RJE501480-001V01
1 1 1 1 1 BJ
A
20
10203355
Common sheet
RJE501477-001V01
1 11 1 1
A
L
A
21
10203353
Spacer
RJE501478-001V01
1 11 1 1
A
EC
22
10203354
FPC
RJE501476-001V01
1 11 1 1
A
S
A
23
10207413
KB chassis
RJE501479-001V01
1 11 1 1
A
M
X
5. Power su
pp
l
y
Block
24 10224256 Power supply unit PS-272A-2D 1 1 CX A
24 10224254 Power supply unit PS-272A-U 1 DB A
24 10224255 Power supply unit PS-272A-1D 1 1 CW A
25 10224253 Power cord M2511-LF 1 1 AZ C
25 10224252 Power cord MP5004-LF 1 BG C
25
10225547
Power cord PS204-A-LF 1 1 1
A
VC
Q't
y
Price
Code
Europe UK USA Canada
Other
Countries
