Casio TE-2400 Service Manual

— 37 —
[ 10 ] CG READ test
[Function]
Perform the READ ONLY test for OG.
[Operation]
Operation : n 0 1 7 SUBTOTAL
n : 0 = One time check (can be omitted)
not 0 = Continuous check (Press “C” key or turn off the power by rotating the key to stop
this test.)
[PRINT]
The address is not printed when the error occurs.
CG 1 7
CG RD OK
END 17
NG is printed if CHECK SUM value is not normal.
[ 11 ] FLASH USER AREA clear test
[Function]
Clear the area of LOCALE/CONTRAST setting.
[Operation]
Operation : 2 1 2 SUBTOTAL
[PRINT]
NG is printed if the test is not done correctly.
ROM 2 1 2
ROM CLR OK
END 21 2

Casio TE-2400 Specifications

General

Types of payment	Cash
Supported paper width	58 mm
Display digits	10 digits
Second display	Yes
Second display type	LED
Display number of characters	16
Power source	AC
AC input voltage	120-230 V
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth	450 mm
Width	400 mm
Height	277 mm
Weight	12000 g
