Casio TE-2400 Service Manual

— 39 —
[ 14 ] Pop-up display test
[Function]
Pop-up display test is performed.
Press any key to end the test.
[Operation]
Operation : 2 2 1 SUBTOTAL
[ 13 ] Backlight test
[Function]
This is a test for the LCD backlight.
[Operation]
Operation : c 0 1 2 1 SUBTOTAL
C : Designating the backlight color
0 = Batch test
The color changes as follows upon the press of keys.
White  Green  Red
1 = OFF
2 = White
3 = Green
4 = White + Green
[PRINT]
When inputting 0 or without inputting in "C", 121 is printed.
When inputting numbers 1 to 4 in "C", the number input on C and 0120 are printed as the figure shown.
BACK L I GHT 12 1
BACK L I GHT OK
END 12 1
BACK L IGHT c0121
BACK L I GHT OK
END c0121
3 4 5 6 7 8 9 0
DIAG 221
1234567890
[Pop-up display]
The following is displayed and cleared after
the test.
[Main display]
[PRINT]
DISP 7SEG 221
DISP 7SEG OK
END 22 1

Casio TE-2400 Specifications

General

Types of payment	Cash
Supported paper width	58 mm
Display digits	10 digits
Second display	Yes
Second display type	LED
Display number of characters	16
Power source	AC
AC input voltage	120-230 V
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth	450 mm
Width	400 mm
Height	277 mm
Weight	12000 g
