Casio TE-2400 Service Manual

— 97 —
DL-2429 for USA
N Item Code No. Parts Name Specification Qty Price Code R
1 10203572 BOX SUB ASSY RJE501440*001V01 1 CY X
10203573 B-CHASSIS ASSY RJE501442*003V01 1 CA X
2 10203587 B-CHASSIS RJE501384-001V01 1 BM X
3 10208224 LOCK ASSY RJE500567*006V01 1 CF A
4 55000619 DELRIN ROLLER DR-19B1 2 AF B
5 10194208 DUMPER RUBBER RJE500005-001V02 4 AD X
10203607 DRAWER ASSY RJE501441*001V01 1 CQ X
6 10223071 DRAWER SUB ASSY E341274*002V04 1 BQ C
7 55000619 DELRIN ROLLER DR-19B1 2 AF B
8 10201065 EARTH SPRING E412092-001V02 1 AC C
9 10203374 CYLINDER LOCK CL-23 1 AZ B
10 10215645 FRONT PANEL RJE501385-001V02 1 AZ C
11 19064150 RIVET 5X30 1 AA X
12 10192854 BILL COIN CASE ASSY RJE501368*003V01 1 CH C
13 10200509 BILL HOLER SUB ASSY E341290*002V03 5 AC A
14 10079063 BILL HOLDER SPRING E441357-1 5 AA A
15 10194233 BILL HOLDER PLATE E240845-001V02 1 AK X
16 10078757 BILL CASE E140505-1 1 BM X
17 10106267 COIN CASE RJE500284-001V01 1 AH C
18 10110335 COIN SEPARATER RJE500285-001V01 4 AA B
19 10106268 BILL SEPARATER RJE500219-001V01 4 AA B
20 10203171 RUBBER LEG CASE RJE500667-001V02 4 AD X
21 10167366 RUBBER LEG RJE501204-001V01 4 AD X

Casio TE-2400 Specifications

General

Types of payment	Cash
Supported paper width	58 mm
Display digits	10 digits
Second display	Yes
Second display type	LED
Display number of characters	16
Power source	AC
AC input voltage	120-230 V
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth	450 mm
Width	400 mm
Height	277 mm
Weight	12000 g
