MSD not seen
Red
Flashing
Orange
3 short
pulses
MSD NOT
SEEN
When ready to join the group, ensure that you are in the work area and press and hold the ‘|’ button for longer
than half a second. Monitor the PSD display for information on linking status. The PSD returns a status message
depending on several factors as displayed in the following table.
If functioning properly, the unit will have a green flashing Status LED and the display will show ‘PSD # ACTIVE’
where # represents the PSD sub-address.
Table 7: PSD Linking Operational States
BUTTON
PRESSED
STATUS
LED
COMM
LOSS LED
LOW BATT
LED
ERRO
R LED
HAPTIC
FEEDBACK
DISPLAY
PSD LINKING STATE
PSD
linking
‘I’ for 500mS
1 short pulse as
soon as link is
established
LINKING
(flashing
until linked
PSD LINKED STATE
PSD
linked
(normal
operation
mode)
Green
(flashing)
1 short pulse (at
state transition to
PSD linked – see
PSD Linking
above)
PSD #
ACTIVE
