Cavli Wireless C100QM/C10QM Hardware Manual
15
interface
✧ Power interface
✧ Network status
indication
✧ General purpose
GPIO interface
Clock frequency up to 50MHz
Maximum capacity supports 32GB
Interface voltage domain is 1.8/2.95V, two voltages
are adjustable
Support 3.3V-4.2V DC power supply
Used to indicate the status of the module, the speed
of the light is on, indicating the status of the module
that is not available.
WAKEUP_IN sleep mode control, low wake-up
module
AP_READY sleep state detection
W_DISABLE# flight mode control
Transmit power
LTE:
Class 3 (23dBm±2dB)
UMTS:
Class 3 (24dBm+1/-3dB)
TD-SCDMA:
Class 2 (24dBm+1/-3dB)
CDMA2000：
Class 3 (24dBm+3/-1dB)
GSM/GPRS:
Class 4 (33dBm±2dB) GSM850/GSM900
Class 1 (30dBm±2dB) DCS1800/PCS1900
