Cavli Wireless C100QM - 2.3 Module Function

Cavli Wireless C100QM/C10QM Hardware Manual
17
Virtual network card
Support USB virtual network card
temperature range
Normal operating temperature -30 ° C to +75 ° C
Extreme operating temperature -40°C to +85°C
storage temperature
-40°C to +85°C
humidity
RH5%～RH95%
Module function distinction
On the label paper, M stands for the main set, D takes
the table diversity, and G stands for GPS.
When the temperature is in the range of –40°C to –30°C or +75°C to +85°C, some
RF specifications of the C100QM/C10QM module may not meet the 3GPP standards.
2.3 Module function
The C100QM/C10QM LCC module mainly contains the following circuit units:
✧ Baseband processing unit
✧ Power Management Unit
✧ memory unit
✧ RF transceiver unit
✧ RF front-end unit
✧ GPS RF receiving unit
The functional block diagram of the C100QM/C10QM LCC module is as follows:
