Cavli Wireless C100QM/C10QM Hardware Manual
3
Contents
Chapter 1. Introduction 10
Chapter 2. Module Overview 11
2.1 Module introduction 11
2.2 Module characteristics 12
2.3 Module function 17
Chapter 3. Interface application description 18
3.1 Chapter overview 18
3.2 Module interface 19
3.2.1 144-pin LCC interface 20
3.2.2 Interface definition 20
3.3 Power interface 30
3.3.1 Power supply design 31
3.3.2 Power reference circuit 32
3.3.3 VDD_SDIO 1.8V/2.85V voltage output 34
3.3.4 VDD_EXT 1V8 voltage output 34
3.4 Switching machine reset mode 34
3.4.1 Boot 34
3.4.2 Boot timing 35
3.4.3 Power down 36
3.4.4 Reset control 36
