Cavli Wireless C100QM - Module Status Indication

Cavli Wireless C100QM/C10QM Hardware Manual
27
not been defined
4
W_DISABLE#
DI
Flight mode control
This pin function is under
development (please keep it
floating when not in use)
5
GPIO_2
PI
This pin function has
not been defined
RESERVE, please keep floating
Module status indication interface
NO.
Definition
IO
Functional description
Remarks
6
NET_STATUS
O
D
Module work network status
light indication
please keep it floating
when not in use
61
STATUS
D
O
Module running status
indication
please keep it floating
when not in use
PCM interface
NO
.
Definition
IO
Functional description
Remarks
24
PCM_IN
DI
PCM receiving data
please keep it floating when not in
use
25
PCM_OUT
D
O
PCM sends data
please keep it floating when not in
use
26
PCM_SYNC
IO
PCM frame sync signal
please keep it floating when not in
use
27
PCM_CLK
IO
PCM clock pulse
please keep it floating when not in
use
I2C interface
