Cavli Wireless C100QM/C10QM Hardware Manual
84
Power) is not less than 100 W.
The protective device PCB layout should be as close as possible to the “V” shaped line
to avoid the “T” shaped line.
The ground plane around the module guarantees integrity and should not be split.
ESD control of the surrounding environment and operators needs to be taken into
account during module production, assembly and laboratory testing.
Table 5-4 C100QM/C10QM ESD Features
Test port
Contact discharge
Air discharge
unit
USB interface
±4
±8
KV
USIM interface
±4
±8
KV
Analog voice interface
±4
±8
KV
VBAT power supply
±4
±8
KV
5.6 Reliability index
Table 5-5 C100QM/C10QM Reliability Test
Test items
Test Conditions
Guideline
Test Results
Low
temperatur
e work
Temperature: 40oC
Working mode: normal
work
Test duration: 24 h
IEC60068-2-1
Visual inspection: normal
Function check: normal
RF indicator check:
normal
High
temperatur
e work
Temperature: 85oC
Working mode: normal
work
Test duration: 24 h
JESD22-A108-
C
Visual inspection: normal
Function check: normal
RF indicator check:
normal
Temperatur
e cycle
High temperature: 85oC
Low temperature: 40oC
Working mode: normal
JESD22-A105-
B
Visual inspection: normal
Function check: normal
RF indicator check:
