Frequency
band
Standing
wave
ratio
Active
antenna noise
figure
Active
antenna gain
Active antenna
embedded LNA gain
GPS L1
1575.41+/1.0
23MHZ
<2:1
<1.5DB
>-2DBi
20DB
GLONASS
1597.5-
1605.8MHZ
<2:1
<1.5DB
>-2DBi
20DB
BeiDou
1559.05-
1563.14MHZ
<2:1
<1.5DB
>-2DBi
20DB
Galileo E1
1573.4-
1577.5MHZ
<2:1
<1.5DB
>-2DBi
20DB
4.7 Power consumption characteristics
Table 4-9 Three major operators' live network sleep and idle power consumption (GNSS off)
Operato
r
System
condition
mode
Current
consumption mA
CMCC
GSM
GPS off, no USB
connection
Sleep mode
1.5
Idle mode
18.1
LTE
GPS off, no USB
connection
Sleep mode
1.0
Idle mode
12.6
CUCC
GSM
GPS off, no USB
connection
Sleep mode
2.3
Idle mode
17.9
WCDMA
GPS off, no USB
Sleep mode
2.3
