Cavli Wireless C100QM - 4.4 Conducted Radio Frequency Measurement

Cavli Wireless C100QM/C10QM Hardware Manual
74
LTE B40
2300MHz– 2400MHz
2300MHz – 2400MHz
TDD
LTE B41
2555MHz– 2655MHz
2555MHz – 2655MHz
TDD
GSM850
824MHz – 849MHz
869MHz – 894MHz
GSM
GSM900
880MHz – 915MHz
925MHz – 960MHz
GSM
GSM1800
1710MHz– 1785MHz
1805MHz – 1880MHz
GSM
UMTS B1
1920MHz –1980MHz
2110MHz – 2170MHz
WCDMA
UMTS B5
824MHz – 849MHz
869MHz – 894MHz
WCDMA
UMTS B8
880MHz – 915MHz
925MHz – 960MHz
WCDMA
TDS B34
2010MHz –2025MHz
2010MHz – 2025MHz
TD-SCDMA
TDS B39
1880MHz –1920MHz
1880MHz – 1920MHz
TD-SCDMA
BC0
824MHz – 849MHz
869MHz – 894MHz
CDMA
4.4 Conducted radio frequency measurement
4.4.1 test environment
Table 4-3 Test instruments
test instrument
power supply
Murata coaxial RF line
R&S CMW500
Agilent 66319
MXHP32HP1000
4.4.2 standard test
The C100QM/C10QM module passes the 3GPP TS 51.010-1, 3GPP TS 34.121-1,
3GPP TS 36.521-1, 3GPP2 C.S0011 and 3GPP2 C.S0033 test standards. Each module is
rigorously tested at the factory to ensure reliable quality.
4.5 Conducted receiving sensitivity and transmit power
The C100QM/C10QM module 2G and 3G receive sensitivity and transmit power test
indicators are as follows:
Table 4-4 2G3G RF indicators
mode
Up
Down
power
Receiving
