Cavli Wireless C100QM - 4.5 Conducted Receiving Sensitivity and Transmit Power

Cavli Wireless C100QM/C10QM Hardware Manual
75
sensitivity
GSM 850
824MHz–
849MHz
869MHz–
894MHz
33±2dBm
<-108dBm
GSM 900
880MHz–
915MHz
925MHz–
960MHz
33±2dBm
<-109dBm
GSM 1800
1710MHz–
1785MHz
1805MHz–
1880MHz
30±2dBm
<-109dBm
WCDMA B1
1920MHz–
1980MHz
2110MHz–
2170MHz
23+2/-2dBm
<-109dBm
WCDMA B5
824MHz–
849MHzz
869MHz–
894MH
23+2/-2dBm
<-109dBm
WCDMA B8
880MHz–
915MHz
925MHz–
960MHz
23+2/-2dBm
<-109dBm
TD-SCDMA
B34
2010MHz–
2025MHz
2010MHz–
2025MHz
24+1/-3dBm
<-109dBm
TD-SCDMA
B39
1880MHz–
1920MHz
1880MHz–
1920MHz
24+1/-3dBm
<-109dBm
EVDOrA
824MHz–
849MHz
869MHz–
894MHz
23+2/-2dBm
<-108dBm
The C100QM/C10QM module 4G receiving sensitivity and transmit power test indicators
are as follows:
Table 4-5 4G RF sensitivity indicators
Directory (sensitivity)
3GPP protocol
requirements
Min
typical
max
LTE B1 (FDD QPSK pass) 95%)
< –96.3(10 MHz)
-99
-98
