WAKEUP_IN:
This pin is the host wake-up module pin. When the WAKEUP_IN signal is pulled low,
the host can wake up the module.
AP_READY (this feature is under development)
The AP_READY pin can be used by the module to detect if the host is woken up and
can be configured for high level detection or low-level detection.
W_DISABLE#:
Flight mode control (this function is under development), when the
C100QM/C10QM module W_DISABLE# signal is pulled low, the module RF function can
be turned off, the module can enter the flight mode, and the module can be turned on to
open the module RF function. It can also be set to flight mode by AT+CFUN. For details,
