Cavli Wireless C100QM/C10QM Hardware Manual
94
MCS 4 = 17.6 kb/s/ time slot
70.4 kb/s
GMSK
MCS 5 = 22.4 kb/s/ time slot
89.6 kb/s
8PSK
MCS 6 = 29.6 kb/s/ time slot
118.4 kb/s
8PSK
MCS 7 = 44.8 kb/s/ time slot
179.2 kb/s
8PSK
MCS 8 = 54.4 kb/s/ time slot
217.6 kb/s
8PSK
MCS 9 = 59.2 kb/s/ time slot
236.8 kb/s
8PSK
Table 8-5 Maximum HSDPA rate
HSDPA device category
Max data rate（peak）
Modulation type
Category 1
1.2Mbps
16QAM,QPSK
Category 2
1.2Mbps
16QAM,QPSK
Category 3
1.8Mbps
16QAM,QPSK
Category 4
1.8Mbps
16QAM,QPSK
Category 5
3.6Mbps
16QAM,QPSK
Category 6
3.6Mbps
16QAM,QPSK
Category 7
7.2Mbps
16QAM,QPSK
Category 8
7.2Mbps
16QAM,QPSK
Category 9
10.2Mbps
16QAM,QPSK
Category 10
14.4Mbps
16QAM,QPSK
Category 11
0.9Mbps
QPSK
Category 12
1.8Mbps
QPSK
Category 13
17.6Mbps
64QAM
Category 14
21.1Mbps
64QAM
Category 15
23.4Mbps
16QAM
Category 16
28Mbps
16QAM
Category 17
23.4Mbps
64QAM
Category 18
28Mbps
64QAM
