TECHNICAL DATA
The CEFAR MYO XT/CEFAR ACTIV XT is an electric muscle
stimulator with two channels, intended for muscle training. The
stimulator can run on two rechargeable 1.2-V AA batteries or
two non-rechargeable 1.5-V AA batteries. It generates 100 mA of
constant current through an external charge of 1000 ohms.
NUMBER OF CHANNELS 2 (4 outputs)
NUMBER OF PROGRAMS CEFAR MYO XT: 82
CEFAR ACTIV XT: 60
CONSTANT CURRENT Up to a resistance of 1000 ohm.
STIMULATION FORMS Continuous stimulation: fixed or modu-
lated frequency at two different pulse
durations.
Intermittent stimulation: fixed frequency
at two different pulse durations.
AMPLITUDE 0-100 mA.
WAVEFORM Symmetrical biphasic square pulse.
MAXIMUM FREQUENCY 80 Hz
MAXIMUM PULSE
DURATION 350 µs
ENERGY SOURCE 2 x 1.5 V AA non-rechargeable or
2 x 1.2 V AA rechargeable batteries.
CURRENT CONSUMPTION
FOR ONE CHANNEL,
350 µS, 60 HZ, 100 mA 450 mA
CONDITIONS FOR STORAGE,
USE AND TRANSPORT Temperature 10º C–40º C
Air humidity 30%–75%
Air pressure 700 hPa–1060 hPa.
EXTERNAL DIMENSIONS 150 x 80 x 27 mm
WEIGHT approximately 200 g
I R.M.S. MAX/CHANNEL 23 mA
KEY TO THE STIMULATOR SYMBOLS
Read the instructions before use.
Patient body part, type BF – Body Floating.
Meets the requirements of MDD 93/42/EEC.
Reported to SGS (0120).
Warranty: The stimulator has a two-year warranty against defects,
on condition that it is used correctly.
350 µs
0120
