Instrument Description
Touch Screen Display
- shows menus, method parameters, etc.
Door Seal
- ensures tight fit between door and interior cavity of the MARS 6 to prevent microwave leakage.
Turntable Drive Lug
- allows the turntable drive shaft to pass through the cavity floor and engage the
turntable.
Door Handle
– permits ease of opening instrument door.
Internal Printer (Optional) -
permits printing of method parameters, graphs and/or method data
Waveguide Covers
– evenly distribute microwaves into instrument cavity
IR Sensors –
Measure temperature at bottom of vessels
Turntable Sensor –
detects type of turntable
Vessel Counting Sensor –
counts number of vessels in the turntable
Display
Printer
Door
Handle
Door Seal
ESP-1500 Plus
Connector Port

CEM MARS 6 Specifications

General

Type	Microwave Digestion System
Power Output	1600 W
Temperature Control	Yes
Pressure Control	Yes
Vessel Capacity	up to 40 vessels
Display	Touchscreen
Operating Pressure	up to 800 psi
Temperature Range	up to 300°C
Temperature Accuracy	± 1 °C
Power Supply	220-240 V, 50/60 Hz
Safety Features	Over-temperature and over-pressure protection
Power Consumption	1600W
Cooling Rate	Forced air cooling
