CEM MARS 6 User Manual

88
9. With the MARS 6 home screen displayed, select the System Menu icon at the bottom right corner of the screen.
10. Select “Tools.”
11. Select “Update Manager.”
12. If any update(s) is available, select the firmware version to download from the “Available” area of the above
screen.
13. Press “Install.”
CAUTION
Firmware update requires approximately 10 - 20 minutes for completion. The system will reboot several
times and may at times display a blank screen. DO NOT turn the instrument off during the loading
process.

CEM MARS 6 Specifications

General

Type	Microwave Digestion System
Power Output	1600 W
Temperature Control	Yes
Pressure Control	Yes
Vessel Capacity	up to 40 vessels
Display	Touchscreen
Operating Pressure	up to 800 psi
Temperature Range	up to 300°C
Temperature Accuracy	± 1 °C
Power Supply	220-240 V, 50/60 Hz
Safety Features	Over-temperature and over-pressure protection
Power Consumption	1600W
Cooling Rate	Forced air cooling
