17. esQUeMa elÉcTRIco GeneRal
1
3 5
7
9 11
2
4
6
8
10 12
0
RL
3 Ph ~
L2
L3
PE
XS1
SPINA E PRESA
Plug & Socket
INVERTITORE COMMUTATORE DI POLARITA’
Reverse Polarity Switch
x 11-12
x 9-10
x 7-8
x 5-6
x 3-4
x 1-2
L 0 R
1
2
3
L1
ELEMENTI - Elements
CONTATTI - Contacts
W2
U1
U2
V2
V1
W1
W2
U1
U2
V2
V1
W1
200-220-240V
380-415-440V
MORSETTIERA Junction Box
F
F
F
Power
Phase
400V / 3 / 50 Hz - 0,55 kW 500V, 4A
400V / 3 / 50 Hz - 0,75 kW 500V, 6A
230V / 3 / 50 Hz - 0,55 kW 250V, 10A
230V / 3 / 50 Hz - 0,75 kW 250V, 10A
200V / 3 / 50 Hz - 0,75 kW (Japan) 250V, 10A
F: Fuse
TYRE CHANGER - 1 SPEED VERSION
3 PHASE
