CEMB SM628TI - 11. Maintenance

46 User’s manual
11. MaInTenance
WARNING
Itisprohibitedtoperformanyoperationthatchangesthepre-setvalueofthepres-
sureregulationvalveorpressurelimiter.Themanufacturerdeclinesallliabilityfor
damageresultingfromtamperingwithsuchvalves.
WARNING
Beforemakinganyadjustmentsorcarryingoutmaintenanceonthemachine,
disconnecttheelectricaland compressedairsupplyandmakesurethat
allmovingpartsarelockedinplace.
WARNING
Donotremoveormodifyanycomponentofthismachine(theseoperations
mayonlybecarriedoutbytechnicalassistancepersonnel).
WARNING
Whenthemachineisdisconnectedfromthepneumaticpowersupply,the
pneumaticactuatorscanremainpressurized.
WARNING
Beforecarryingoutanyregularmaintenanceoperationortoppingupwithlubricant,
disconnectthemachinefromthecompressedairsupplyline.
WARNING
Themanufacturerdeclinesallresponsibilityforclaimsresultingfromtheuse
ofnon-originalsparepartsoraccessories.
- Regularly clean the machine from dirt
- Keep all guides clean and lubricated (vertical axis, horizontal axis, jaw guides)
- The purpose of the regulator lter and lubricator (FRL) unit is to lter the air, adjust the
pressure and lubricate it.
The “FRL” unit supports a maximum input pressure of 16 bar and has an adjustment
range between 0.5 to 10bar, this adjustment can be modied by pulling the handle to
the extracted position and turning it. At the end of the adjustment, return the handle to
the locked position pushing it downwards (g.38a).
The lubricant ow rate adjustment is carried out by turning the screw on the element “L”,
