CEMB SM628TI - 8. Main Working Elements of the Machine; 8.1 Commands

28 User’s manual
8. MaIn WoRKInG eleMenTs of THe
MacHIne
WARNING
Learnyourmachine:knowingexactlyhowthemachineworksisthebestway
toguaranteesafetyandmachineperformance.
Learnthefunctionandlayoutofallcontrols.
Carefullycheckthatallcontrolsonthemachineareworkingproperly.
Toavoidaccidentsandinjury,themachinemustbe installedproperly,operated
correctlyandservicedregularly.
1 Turntable
2 Clamp
3 Vertical arm
4 Horizontal arm
5 Mounting bare
6 Vertical arm lever locking
7 Mounting head
8 Air lubricator
9 Bead breaker arm
10 Bead breaker
11 Wheel support
15 Tyre lever
16 Shoe guard (option)
17 Inator pedal for t.i. version
18 Air tank
19 Swivelling arm adjustment handle
8.1 COMMANDS
8.1.a. PEDAL:
12 Bead breaker control pedal (monostable pedal to operate the bead breaker shoe)
13 Locking wedges opening and closing control pedal (stable three-position pedal
for opening and closing wedges).
14 Turntable rotation control pedal, two-position pedal (three-position only 2V):
• Position 0 (stable) turntable stationary
• Pressed downwards (unstable position), rotate clockwise.
• Lifted (Unstable position) anticlockwise rotation.
8.1.b.PRESSURE GAUGE WITH DEFLATION PUSH-BUTTON:
20 Pressure gauge
21 Tyre deating push button
