Centa CENTAX-L - Page 15

Assembly and operating instructions
CENTAX-L
016L-00050…00090-FS10
M016-00003-EN
Rev. 3
CENTA Antriebe Kirschey GmbH 15 / 46
Size
Shorehardeness
[Shore A]
∆K
R max
[mm]
50 - 56
45 / 50 / 60
±0.45
70
±0.15
64 - 65
50 / 60
±0.45
70
±0.15
66 - 70
50 / 60
±0.6
70
±0.18
72
50 / 60
±0.75
70
±0.22
75
50 / 60
±0.82
70
±0.25
78
50 / 60
±0.9
70
±0.3
80
50 / 60
±1.05
70
±0.33
81
50 / 60
±1.05
70
±0.37
82 - 90
50 / 60
±1.2
70
±0.37
Table 5-1 Permissible radial alignment tolerance
