7 Operation
WARNING
Injury and material damage can occur as a result of:
 Worn coupling components
If the running noises change and/or vibrations occur turn the plant off
immediately.
Determine the fault and its root cause, and remedy.
The troubleshooting process is simplified by the table in the next chapter.
On principle in case of a fault, an analysis of the entire plant should be
performed.
7.1 Operating faults, root causes and remedy
Faults
Possible root
causes
Remedy
Running noises or
vibrations in the
plant
Alignment error
1. Switch off the plant
2. Check alignment, correct if applicable
3. Trial run
Loose screws
1. Switch off the plant
2. Check alignment, correct if applicable
3. Check screw torque levels and correct if
necessary
4. Trial run
Breakage of the
rubber element
Alignment error
1. Switch off the plant
2. Exchange defective parts
3. Check alignment, correct if applicable
4. Trial run
Inadmissibly high
torque
1. Switch off the plant
2. Exchange defective parts
3. Check alignment, correct if applicable
4. Trial run
Table 7-1 Troubleshooting table
In case of uncertainty or if you have questions, please contact our head office
(address see chapter 1).
7.2 Admissible overall misalignment of the coupling
The overall misalignment values can be found in the catalogue.
