Push the bolts (6) into the drillings (f; 2x180°) of the link flange assembly
(1) and secure them with the circlips (7).
Turn the link flange assembly (1) towards the adapter (8) until the drillings
(e) in the adapter (8) and the bolts (6) are aligned.
Push the link flange assembly (1) towards the adapter (8) until a distance of
approx. 5 mm is reached.
By doing so, place the bolts (6) in drillings (e) of the adapter (8).
Push the screws (9) with the washers (10) into the drillings of the link flange
assembly (1).
Push the sheets (4) onto the screws (9).
Screw the link flange assembly (1) and the sheets (4) to the adapter (8)
using the screws (9) and the washers (10; if existing).
6.7 Mounting the links
The links must be mounted in such a way that they are subjected to tensile load.A
differentiation is made between the direction of rotation left (ccw) and right (cw),
looking towards the driving end.
Links are packaged in sets.
All links of a link set are the same weight.
Only mount links in complete sets "crosswise".
Instructions on how to mount one link are provided following. Item numbers and
the part illustrations may differ slightly from the delivery state.
The following table gives an overview of the number of size of the links used.
