Assembly and operating instructions
CENTAX-L
016L-00050…00090-FS10
M016-00003-EN
Rev. 3
CENTA Antriebe Kirschey GmbH 28 / 46
6.6 Mounting the link flange assembly (1)
 Mount the link flange assembly as appropriate for the supplied design (see
installation drawing):
 Mounting the link flange assembly with/without sheet (5),
see chapter 6.6.1 .
 Mounting the link flange assembly and the adapter (8),
see chapter 6.6.2 .
6.6.1 Mounting the link flange assembly with/without sheet (5)
Fig. 6-6 Mounting the link flange assembly with/without sheet (5)
Item
Info
Designation
Remark
1
Link flange assembly
Pre-mounted by CENTA
3
Hub
5
Sheet
See installation drawing
30
Washer
If ordered
31
Screw
If ordered
B
Flywheel
Customer part
